Current location:Home > Products >Thick Film Chip Resistors > Complete Pb-Free Thick Film Chip Resistors - PF
Click to show
Series | Product Name | Photo | Power | Specifications | Temperature coefficient | Precision | Resistance segment | Specifications | Details |
---|---|---|---|---|---|---|---|---|---|
PF | Complete Pb-Free Thick Film Chip Resistors | 1W | PF12 | ±100ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1W | PF12 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1W | PF12 | ±400ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 3/4W | PF10 | ±100ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 3/4W | PF10 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 3/4W | PF10 | ±400ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 3/4W | PF11 | ±100ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 3/4W | PF11 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 3/4W | PF11 | ±400ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/2W | PF07 | ±100ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/2W | PF07 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/2W | PF07 | ±400ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/4W | PF06 | ±100ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/4W | PF06 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/4W | PF06 | ±400ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/8W | PF05 | ±100ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/8W | PF05 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/8W | PF05 | ±400ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/10W | PF03 | ±100ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/10W | PF03 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/10W | PF03 | ±400ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/16W | PF02 | ±100ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/16W | PF02 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/16W | PF02 | ±400ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/20W | PF01 | ±200ppm/℃ | ±1% ±5% | 10Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/20W | PF01 | -100~+350ppm/℃ | ±1% ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/32W | PF0A | ±200ppm/℃ | ±1% ±5% | 100Ω<R≤10MΩ | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/32W | PF0A | ±300ppm/℃ | ±1% ±5% | 10Ω<R≤100Ω | File size:723.32 KB |
Details | |
PF | Complete Pb-Free Thick Film Chip Resistors | 1/32W | PF0A | -200~+600ppm/℃ | ±5% | 1Ω≤R≤10Ω | File size:723.32 KB |
Details |
