The company mainly produces and sells various types of fixed resistors such as chip resistors, network resistors, plug-in resistors, cement resistors, and power resistors. Its customers are located in major cities in China and exported to Europe, America,
Current location:Home > Products >Thick Film Chip Resistors > High Ohmic Value Thick Film Resistors
Click to show
Series | Product Name | Photo | Power | Specifications | Temperature coefficient | Precision | Resistance segment | Specifications | Details |
---|---|---|---|---|---|---|---|---|---|
General | High Ohmic Value Thick Film Resistors | 1/2W | 1210 | ±200ppm/℃ | ±5% | 10MΩ≤R≤100MΩ | File size:562.13 KB |
Details | |
General | High Ohmic Value Thick Film Resistors | 1/4W | 1206 | ±200ppm/℃ | ±5% | 10MΩ≤R≤100MΩ | File size:562.13 KB |
Details | |
General | High Ohmic Value Thick Film Resistors | 1/8W | 0805 | ±200ppm/℃ | ±5% | 10MΩ≤R≤100MΩ | File size:562.13 KB |
Details | |
General | High Ohmic Value Thick Film Resistors | 1/10W | 0603 | ±200ppm/℃ | ±5% | 10MΩ≤R≤100MΩ | File size:562.13 KB |
Details |
