Current location:Home > Products >Thick Film Chip Resistors > Automotive Low Resistance Thick Film Chip Resistors-CS

Click to show

Show 39 Series results

If you need to download the specifications of related products, please click the box in front of your required specifications to be checked, please click the Download PDF button at the top of the form to download the complete specifications .
Download PDF
Series Product Name Photo Power Specifications Temperature coefficient Precision Resistance segment Specifications Details
CS Automotive Low Resistance Thick Film Chip Resistors 1W CS12 ±100ppm/℃ ±1% ±5% 0.1Ω<R≤1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1W CS12 ±150ppm/℃ ±1% ±5% 50mΩ<R≤0.1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1W CS12 ±200ppm/℃ ±1% ±5% 33mΩ<R≤50mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1W CS12 ±300ppm/℃ ±1% ±5% 20mΩ≤R≤30mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1W CS12 ±400ppm/℃ ±1% ±5% 15mΩ≤R<20mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1W CS12 ±600ppm/℃ ±1% ±5% 10mΩ≤R<15mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS11 ±100ppm/℃ ±1% ±5% 0.1Ω<R≤1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS11 ±200ppm/℃ ±1% ±5% 50mΩ≤R≤0.1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS11 ±400ppm/℃ ±1% ±5% 20mΩ≤R<50mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS11 ±500ppm/℃ ±1% ±5% 10mΩ≤R<20mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS10 ±100ppm/℃ ±1% ±5% 0.1Ω<R≤1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS10 ±150ppm/℃ ±1% ±5% 50mΩ<R≤0.1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS10 ±200ppm/℃ ±1% ±5% 33mΩ<R≤50mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS10 ±300ppm/℃ ±1% ±5% 20mΩ≤R≤30mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS10 ±500ppm/℃ ±1% ±5% 15mΩ≤R<20mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 3/4W CS10 ±600ppm/℃ ±1% ±5% 10mΩ≤R<15mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/2W CS07 ±100ppm/℃ ±1% ±5% 50mΩ<R≤1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/2W CS07 ±300ppm/℃ ±1% ±5% 20mΩ≤R≤50mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/2W CS07 ±400ppm/℃ ±1% ±5% 15mΩ≤R<20mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/2W CS07 ±500ppm/℃ ±1% ±5% 10mΩ≤R<15mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/3W CS06 ±150ppm/℃ ±1% ±5% 0.1Ω<R≤1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/3W CS06 ±200ppm/℃ ±1% ±5% 50mΩ<R≤0.1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/3W CS06 ±300ppm/℃ ±1% ±5% 30mΩ<R≤50mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/3W CS06 ±400ppm/℃ ±1% ±5% 15mΩ≤R≤30mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/3W CS06 ±700ppm/℃ ±1% ±5% 10mΩ≤R<15mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/4W CS05 ±100ppm/℃ ±1% ±5% 0.2Ω<R≤1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/4W CS05 ±200ppm/℃ ±1% ±5% 50mΩ<R≤0.2Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/4W CS05 ±400ppm/℃ ±1% ±5% 25mΩ<R≤50mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/4W CS05 ±600ppm/℃ ±1% ±5% 15mΩ<R≤25mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/4W CS05 ±800ppm/℃ ±1% ±5% 10mΩ≤R≤15mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/5W CS03 ±200ppm/℃ ±1% ±5% 0.1Ω<R≤1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/5W CS03 ±300ppm/℃ ±1% ±5% 50mΩ<R≤0.1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/5W CS03 ±400ppm/℃ ±1% ±5% 33mΩ≤R≤50mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/5W CS03 ±600ppm/℃ ±1% ±5% 30mΩ≤R<33mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/5W CS03 ±800ppm/℃ ±1% ±5% 20mΩ≤R≤30mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/5W CS03 ±1000ppm/℃ ±1% ±5% 15mΩ≤R<20mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/5W CS03 ±1500ppm/℃ ±1% ±5% 10mΩ≤R<15mΩ
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/8W CS02 ±200ppm/℃ ±1% ±5% 100mΩ≤R≤1Ω
File size:616.02 KB
Details
CS Automotive Low Resistance Thick Film Chip Resistors 1/8W CS02 ±700ppm/℃ ±1% ±5% 50mΩ≤R<100mΩ
File size:616.02 KB
Details
